Product introduction
The diaphragm pressure gauge is a closed system consisting of a diaphragm body and a pressure gauge, filled with sealing
fluid. When pressure acts on the diaphragm, the diaphragm deforms. The sealing fluid transmits force to the elastic component
in the pressure gauge head, and the pressure gauge head displays the pressure value. The force transmission of the diaphragm
pressure gauge is completed by the liquid filled between the inside of the diaphragm body and the Bourdon tube of the gauge.
The elastic element is still a Bourdon tube. The diaphragm isolates the corrosive fluid from the pressure gauge, thereby
protecting it from corrosion.
Unit:mm
